Overhead Aerial OPGW Fiber Optic Cable 30 Core Crush Resistant

Name: Overhead Aerial OPGW Fiber Optic Cable 30 Core Crush Resistant
Brand: guangzhou fiber cablepuls co ltd
SKU: OPGW-30B1.3
Price: 190.00 USD
Availability: InStock

Product Details

Place of Origin: GUANGZHOU/CHINA

Brand Name: PUNAISGD

Certification: ISO/CE/ROSH

Model Number: OPGW-30B1.3

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 2km

Price: negotiable

Packaging Details: Wooden Spool ，Φ1200*750mm

Delivery Time: 5-25days

Payment Terms: 30%TT as deposit,70%Balance before shipping.

Supply Ability: 100km

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                Aerial OPGW Fiber Optic Cable, Overhead OPGW Fiber Optic Cable, OPGW Fiber Cable 30 Core


Item No.:	OPGW-30B1.3	Type:	Unit Tube /multi Tube
Outer /Inner Sheath Material:	AA/ACS Wire	Installation Method:	Overhead
Cable Length:	2km-6km Or As Customerized	Warranty Period:	25 Years

Item No.:	OPGW-30B1.3
Type:	Unit Tube /multi Tube
Outer /Inner Sheath Material:	AA/ACS Wire
Installation Method:	Overhead
Cable Length:	2km-6km Or As Customerized
Warranty Period:	25 Years

Overhead Aerial OPGW Fiber Optic Cable 30 Core Crush Resistant

Opgw Cable Ground Wire 30 Core OPGW Fiber Optic Cable Overhead Aerial Use

Product Features

Preferred option for easy handling and splicing.

Thick-walled aluminum pipe (stainless steel) provides excellent crush resistance.

Hermetically sealed pipe protects optical fibers.

Outer wire strands selected to optimize mechanical and electrical properties.

Optical sub-unit provides exceptional mechanical and thermal protection for fibers.

Dielectric color-coded optical sub-units are available in fiber counts of 6, 8, 12, 18 and 24.

Multiple sub-units combine to achieve fiber counts up to 144.

Small cable diameter and light weight.

Obtaining appropriate primary fiber excess length within stainless steel tube.

The OPGW has good tensile, impact and crush resistance performance.

Matching with the different ground wire.

Parameters
No. of Core	2-42	44-72	74-84	86-96	98-108	110-120	122-132	134-144
OD(mm)	10.4	11.2	12.2	14.0	14.8	15.8	16.6	17.4
Cable Weight(kg/km	90	100	115	180	195	220	240	265

Overhead Aerial OPGW Fiber Optic Cable 30 Core Crush Resistant 0

Overhead Aerial OPGW Fiber Optic Cable 30 Core Crush Resistant 1

Production Supplier Profile
Overhead Aerial OPGW Fiber Optic Cable 30 Core Crush Resistant 3

How do I place an OEM or customized order?
1) Send your purchase intention to our email: cotton@fibercablepuls.com
2) Our sales team will contact you to confirm the product specification, packaging, printing, quantity,
and other specific information.
3) Sign the contract or Proforma Invoice.
4) After receiving your deposit, we will start to arrange the production.
5) 2 weeks before the completion of production, we will notify you to start contacting shipping.
