ADSS Fiber Optic Cable 24F Double Jacket PE Aerial Self-Supporting

Name: ADSS Fiber Optic Cable 24F Double Jacket PE Aerial Self-Supporting
Brand: guangzhou fiber cablepuls co ltd
SKU: ADSS-24B1.3
Price: 190.00 USD
Availability: InStock

Product Details

Place of Origin: GUANGZHOU/CHINA

Brand Name: PUNAISGD

Certification: ISO/CE/ROSH

Model Number: ADSS-24B1.3

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1km

Price: negotiate

Packaging Details: Wooden Spool /drum

Delivery Time: 5-25 days

Payment Terms: 30% TT as deposit, 70% Balance before shipping

Supply Ability: 100km

Get Best Price

Chat now

Product Details

Product Description

Highlight:
                                                                                                                                                                                                            Double Jacket PE ADSS Cable, Loose Multi-Tube ADSS Cable, 24F ADSS Cable


Model Number:	ADSS-24B1.3	Length:	2km/3km/4km
Fiber Count:	24/36/48/72/144	Jacket:	PE/DOUBLE JACKET
Colour:	Black	Strength Member:	Double Sheath Double Armored
SPAN:	400M

Model Number:	ADSS-24B1.3
Length:	2km/3km/4km
Fiber Count:	24/36/48/72/144
Jacket:	PE/DOUBLE JACKET
Colour:	Black
Strength Member:	Double Sheath Double Armored
SPAN:	400M

ADSS Fiber Optic Cable 24F Double Jacket PE Aerial Self-Supporting

ADSS Cable 24F Fibra Óptica, Double Jacket PE All Dielectric Self-Supporting Aerial Loose Multi-Tube, Aramid Yarn

Product Specifications

Attribute	Value
Model Number	ADSS-24B1.3
Length	2km/3km/4km
Fiber count	24/36/48/72/144
Jacket	PE/DOUBLE JACKET
Color	Black
Strength member	Double sheath double armored
SPAN	400M

Product Description

ADSS cable is loose tube stranded. Fiber, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tubes (and fillers) are stranded around a FRP (Fiber Reinforced Plastic) as a non-metallic central strength member into a compact and circular cable core.

After the cable core is filled with filling compound, it is covered with thin PE (polyethylene) inner sheath. After stranded layer of aramid yarns are applied over the inner sheath as strength member, the cable is completed with PE or AT (anti-tracking) outer sheath.

ADSS Cable 24F Fibra Óptica product image

Technical Specifications

Item	Fibre Count	6	12	24	48	72	96	144	288
Loose Tube	Tubes* Fibres/Tube	1x6	2x6	4x6	6x8	4x12	6x12	8x12	12x12	24x12
Outer diameter (mm)		1.8	2.0	2.5	2.5	2.5	2.5

Fiber Parameters

No.	Items	Unit	Specification G.652D
1	Mode Field Diameter	1310nm μm	9.2±0.4
		1550nm μm	10.4±0.8
2	Cladding Diameter	μm	125.0±1.0
3	Cladding Non-Circularity	%	≤1.0
