Product Details
Place of Origin: GUANGZHOU/CHINA
Brand Name: PUNAISGD/CABLEPULS
Certification: ISO/CE/ROSH
Model Number: GJXH-1G657A
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 2km
Packaging Details: Wooden Spool /drum
Delivery Time: 5-25days
Payment Terms: 30%TT as deposit,70%Balance before shipping.
Supply Ability: 1000km
|
MODEL:
|
GJXH-1G657A
|
Applications:
|
Indoor Ftth Cabling
|
Steel:
|
0.45mm
|
Fiber Count:
|
1-4 Fibers
|
Cable Weight:
|
32KG±1KG
|
Construction:
|
2pcs Steels OR FRP
|
|
MODEL:
|
GJXH-1G657A
|
|
Applications:
|
Indoor Ftth Cabling
|
|
Steel:
|
0.45mm
|
|
Fiber Count:
|
1-4 Fibers
|
|
Cable Weight:
|
32KG±1KG
|
|
Construction:
|
2pcs Steels OR FRP
|
| Attribute | Value |
|---|---|
| MODEL | GJXH-1G657A |
| Applications | indoor ftth cabling |
| Steel | 0.45mm |
| Fiber Count | 1-4 fibers |
| Cable Weight | 32KG±1KG |
| Construction | 2pcs steels OR FRP |
| Cable Type | Fiber Count | Cable Size mm | Cable Weight Kg/km | Tensile Strength Long/Short term N |
|---|---|---|---|---|
| GJXH-1 | 1 | 2.0*3.0±0.2 | 9.0 | 40/80 |
| GJXH-2 | 2 | 2.0*3.0±0.2 | 9.0 | 40/80 |
| GJXH-4 | 4 | 2.0*3.0±0.2 | 9.0 | 40/80 |
| GJXH-6 | 6 | 2.0*3.0±0.2 | 9.0 | 40/80 |
| GJXH-8 | 8 | 2.5*3.5±0.2 | 11.0 | 40/80 |
| GJXH-12 | 12 | 2.5*3.5±0.2 | 11.0 | 40/80 |
| Item | Unit | Specification |
|---|---|---|
| Fiber Type | G652D | |
| Mode field Diameter | 1310nm μm | 9.2±0.4 |
| 1550nm μm | 10.4±0.8 | |
| Cladding diameter | μm | 125.0±0.1 |
| Cladding non-circularity | % | ≤1.0 |
| Core/cladding concentricity error | μm | ≤0.5 |
| Coating diameter | μm | 245±7 |
| Coating/cladding concentricity error | μm | ≤12 |
| Cable cut-off wavelength | μm | ≤1260 |
| Attenuation Coefficient | 1310nm db/km | ≤0.36 |
| 1550nm db/km | ≤0.22 | |
| Proof stress level | kpsi | ≥100 |
