GCYFY-36B1.3 Air Blown Micro Cable G.652D/G657a1 PE Sheath

Name: GCYFY-36B1.3 Air Blown Micro Cable G.652D/G657a1 PE Sheath
Brand: guangzhou fiber cablepuls co ltd
SKU: GCYFY-36B1.3
Price: 190.00 USD
Availability: InStock

Product Details

Place of Origin: GUANGZHOU/CHINA

Brand Name: PUNAISGD/CABLEPULS

Certification: ISO/CE/ROSH

Model Number: GCYFY-36B1.3

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 2km

Price: negotiate

Packaging Details: Wooden Spool /drum

Delivery Time: 5-25days

Payment Terms: 30%TT as deposit,70%Balance before shipping.

Supply Ability: 100km

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                            288F Air Blown Micro Cable, Dry Core Air Blown Micro Cable, GCYFY Air Blown Micro Cable


Model:	GCYFY-36B1.3	Item:	Air Blown Micro Cable
Jacket Material:	PE Sheath	Fiber Type:	G.652D/G657a1
Cable Color:	Black

Model:	GCYFY-36B1.3
Item:	Air Blown Micro Cable
Jacket Material:	PE Sheath
Fiber Type:	G.652D/G657a1
Cable Color:	Black

GCYFY-36B1.3 Air Blown Micro Cable G.652D/G657a1 PE Sheath

Air Blown Micro Cable Factory JET 12 24 48 72 96 144 288F GCYFTY/GCYFY Dry Core Air Blown Fiber Optic Cable

Product Specifications

Attribute	Value
Model	GCYFY-36B1.3
Item	Air blown micro cable
Jacket Material	PE sheath
Fiber Type	G.652D/G657a1
Cable Color	Black

Product Description

The miniature JET cable structure consists of 250µm single-mode or multi-mode optical fibers enclosed in a loose tube made of high modulus material, filled with non-toxic waterproof compounds. The assembly is reinforced with non-metallic aramid elements and sheathed in black or colored high-density polyethylene (HDPE).

Key Features

Compact size and lightweight design
Tube filling compound provides essential fiber protection
Grooved sheath design ensures optimal air blowing performance
Phased installation capability reduces initial investment
High blowing speed (up to 50m/min) and long distance (up to 1000m)
Allows for cable replacement to maintain technical superiority
Enables branching without affecting other cables, saving on infrastructure

Technical Characteristics

Small diameter, lightweight construction with moderate hardness for air-blow installation
Non-metallic structure eliminates grounding requirements

Technical Data Sheet

Fiber Count	CSM Diameter	Jacket Thickness	Cable Diameter	Cable Weight	Bending Radius
2-12	1.4/1.4	1.6	3.5	11	10D/20D
14-24	1.4/1.4	1.6	4.1	14	10D/20D
26-72	1.4/1.4	1.6	5.0	22	10D/20D
74-96	1.4/1.4	1.6	5.9	33	10D/20D
98-120	1.4/1.4	1.6	7.0	43	10D/20D
122-144	1.6/1.6	1.6	7.7	52	10D/20D
146-216	1.6/1.6	1.6	7.9	52	10D/20D
218-288	1.6/1.6	1.6	9.0	72	10D/20D

Fiber Specifications

Item	Unit	Specification
Fiber Type		G652D
Mode Field Diameter (1310nm)	μm	9.2±0.4
Mode Field Diameter (1550nm)	μm	10.4±0.8
Cladding Diameter	μm	125.0±0.1
Cladding Non-Circularity	%	≤1.0
Core/Cladding Concentricity Error	μm	≤0.5
Coating Diameter	μm	245±7
Coating/Cladding Concentricity Error	μm	≤12
Cable Cut-Off Wavelength	μm	≤1260
Attenuation Coefficient (1310nm)	db/km	≤0.36
Attenuation Coefficient (1550nm)	db/km	≤0.22
Proof Stress Level	kpsi	≥100

Note: Other parameters meet standard ITU-T G.652

Cable Marking & Fiber Colors

COMPANY Fiber cable name N*cores G.652D 2024 XXXXm

*The marking is printed every 1 meter
**"G.652D" means ITU-T Rec. Low Water Peak (LWP) G.652 single mode optical fiber

Custom cable marking available according to client requirements.

Production Supplier Profile

OEM & Customized Order Process

Send your purchase intention to our email: cotton@fibercablepuls.com
Our sales team will contact you to confirm product specifications, packaging, printing, quantity, and other requirements
Sign the contract or Proforma Invoice
After receiving your deposit, we will begin production
Two weeks before production completion, we will notify you to arrange shipping
