Name: FPV Drone Optical Fiber 0.5mm Fiber 3km 5km 10km Option
Brand: guangzhou fiber cablepuls co ltd
SKU: FPV DRONE OPTICAL FIBER
Price: 190.00 USD
Availability: InStock

Product Details

Place of Origin: GUANGZHOU

Brand Name: PUNAISGD

Model Number: FPV DRONE OPTICAL FIBER

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 5km/10km

Price: negotiate

Packaging Details: Spool

Delivery Time: 7DAYS

Payment Terms: T/T

Supply Ability: 100000KM

Get Best Price

Product Details

Product Description

Highlight:
                                                5km FPV Drone Optical Fiber, 10km FPV Drone Optical Fiber, 3km FPV Drone Optical Fiber


FPV Drone Optical Fiber 0.5mm Fiber 3km 5km 10km Option

FPV Drone Optical Fiber 0.5mm Fiber 3km 5km 10km Option FPV Fibre Optic Communications

0. 4mm/0.43mm/0.38mm/0.35mm Invisible Tight Buffer Fiber;
Simplex core for G.657.A2;
tensile:60N
dimensions: diameter:110mm
length:310mm

FPV Drone Optical Fiber 0.5mm Fiber 3km 5km 10km Option 0

Fiber Parameters

No.	Items			Unit	Specification
					G.657A2
1	Mode Field Diameter		1310nm	μm	8.8±0.4
			1550nm	μm	9.8±0.5
2	Cladding Diameter			μm	125±0.7
3	Cladding Non-Circularity			%	≤0.7
4	Core-Cladding Concentricity Error			μm	≤0.5
5	Coating Diameter			μm	245±5
6	Coating Non-Circularity			%	≤6.0
7	Cladding-Coating Concentricity Error			μm	≤12.0
8	Cable Cutoff Wavelength			nm	λcc≤1260
9	Attenuation(max.)		1310nm	dB/km	≤0.35
			1550nm	dB/km	≤0.21
10	Macro-Bending Loss	1turn×7.5mm radius @1550nm		dB	≤0.2
		1turn×7.5mm radius @1625nm		dB	≤0.5
