Name: FPV Drone Optical Fiber 0.5mm G.657.A2 3km 5km 10km
Brand: guangzhou fiber cablepuls co ltd
SKU: FPV DRONE OPTICAL FIBER
Price: 190.00 USD
Availability: InStock

Product Details

Place of Origin: GUANGZHOU

Brand Name: PUNAISGD

Model Number: FPV DRONE OPTICAL FIBER

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 5km/10km

Price: negotiate

Packaging Details: Spool

Delivery Time: 7DAYS

Payment Terms: T/T

Supply Ability: 100000KM

Get Best Price

Product Details

Product Description

Highlight:
                                    5km FPV Drone Optical Fiber, 10km FPV Drone Optical Fiber, 3km FPV Drone Optical Fiber


FPV Drone Optical Fiber 0.5mm G.657.A2 3km 5km 10km

FPV Drone Optical Fiber 0.5mm Fiber with 3km, 5km, and 10km Options

Product Overview

High-performance FPV fiber optic communications cable designed for drone applications, available in multiple length options with superior optical characteristics.

Key Features

Available in 0.4mm, 0.43mm, 0.38mm, and 0.35mm invisible tight buffer fiber options
Simplex core compliant with G.657.A2 standard
High tensile strength: 60N
Compact dimensions: 110mm diameter × 310mm length

Fiber Specifications

Parameter	Wavelength	Unit	Specification (G.657A2)
Mode Field Diameter	1310nm	μm	8.8±0.4
Mode Field Diameter	1550nm	μm	9.8±0.5
Cladding Diameter	-	μm	125±0.7
Cladding Non-Circularity	-	%	≤0.7
Core-Cladding Concentricity Error	-	μm	≤0.5
Coating Diameter	-	μm	245±5
Coating Non-Circularity	-	%	≤6.0
Cladding-Coating Concentricity Error	-	μm	≤12.0
Cable Cutoff Wavelength	-	nm	λcc≤1260
Attenuation (max.)	1310nm	dB/km	≤0.35
Attenuation (max.)	1550nm	dB/km	≤0.21
Macro-Bending Loss	1turn×7.5mm radius @1550nm	dB	≤0.2
Macro-Bending Loss	1turn×7.5mm radius @1625nm	dB	≤0.5

Cable Specifications

Parameter	Specification
Fiber count	1
Tight-Buffer Diameter	0.4±0.01mm
Tight-Buffer Material	PVC (Transparent)
