Product Details
Place of Origin: GUANGZHOU/CHINA
Brand Name: PUNAISGD/CABLEPULS
Certification: ISO/CE/ROSH
Model Number: ASU-120
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 2km
Packaging Details: Wooden Spool /drum
Delivery Time: 5-25days
Payment Terms: 30%TT as deposit,70%Balance before shipping.
Supply Ability: 100km
|
Fiber Count:
|
12
|
Installation Method:
|
Aerial
|
Strength Member Material:
|
FRP*2
|
Cable Diameter:
|
7mm/8mm
|
Span:
|
80m-120m
|
Length:
|
2km-5km
|
Model:
|
ASU CABLE
|
|
Fiber Count:
|
12
|
|
Installation Method:
|
Aerial
|
|
Strength Member Material:
|
FRP*2
|
|
Cable Diameter:
|
7mm/8mm
|
|
Span:
|
80m-120m
|
|
Length:
|
2km-5km
|
|
Model:
|
ASU CABLE
|
| Attribute | Value |
|---|---|
| Fiber Count | 12 |
| Installation Method | Aerial |
| Strength Member Material | FRP*2 |
| Cable Diameter | 7mm/8mm |
| Span | 80m-120m |
| Length | 2km-5km |
| Model | ASU CABLE |
| No. of cable | 12 | 24 | |
|---|---|---|---|
| Fiber Model | G.652D | ||
| Loose Tube | Material | PBT | |
| Diameter | 2.5±0.1mm | 2.8±0.1mm | |
| Thickness | 0.32±0.05 mm | ||
| Color | Nature | ||
| Strength Member | Material | FRP | |
| Diameter | 2.5±0.05 mm | 2.5±0.1mm | |
| Outer Sheath | Material | PE | |
| Color | Black | ||
| Cable Diameter | 8.0±0.2 mm | 8.5±0.2 mm | |
| Cable Weight | 55±5.0 kg/km | 65±5.0 kg/km | |
| Allowable Tensile Strength | 1000N | 1500N | |
| Allowable Crush Resistance | 1100N/100mm | 2200N/100mm | |
| Min. bending radius | Without Tension: 10.0×Cable-φ Under Maximum Tension: 20.0×Cable-φ |
||
| Temperature range (℃) | Installation: -20~+60 Transport & Storage: -40~+70 Operation: -40~+70 |
||
