Product Details
Place of Origin: GUANGZHOU/CHINA
Brand Name: CABLEPULS
Certification: ISO/CE/ROSH
Model Number: GJYXFCH-2b6
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 2km
Price: negotiate
Packaging Details: Wooden Spool /drum
Delivery Time: 5-25days
Payment Terms: 30%TT as deposit,70%Balance before shipping.
Supply Ability: 100km
|
Cable Model:
|
GJYXCH/GJYXFCH-2b6
|
Outer Sheath Color:
|
Black/white
|
Cable Length:
|
1km 2km
|
Feature:
|
Flame Retardant Characteristics
|
Jacket:
|
LSZH
|
Installation Style:
|
Indoor & Outdoor Self-Support Drop Cable
|
Messenger Wire:
|
Steel
|
|
Cable Model:
|
GJYXCH/GJYXFCH-2b6
|
|
Outer Sheath Color:
|
Black/white
|
|
Cable Length:
|
1km 2km
|
|
Feature:
|
Flame Retardant Characteristics
|
|
Jacket:
|
LSZH
|
|
Installation Style:
|
Indoor & Outdoor Self-Support Drop Cable
|
|
Messenger Wire:
|
Steel
|
| Cable Model | GJYXCH/GJYXFCH-2b6 |
| Outer Sheath Color | Black/white |
| Cable Length | 1km 2km |
| Feature | Flame retardant characteristics |
| Jacket | LSZH |
| Installation Style | Indoor & Outdoor Self-Support Drop Cable |
| Messenger Wire | Steel |
FTTH Cable directly connected to their homes, their bandwidth, wavelength and transmission technology type are not restricted. The optical fiber unit is positioned in the centre. Two parallel strength members are placed at the two sides. A steel wire as the additional strength member is also applied, then, the cable is completed with a black HDPE sheath.
| Attenuation @ 1310 nm | ≤ 0.36 dB/km |
| Attenuation @ 1550 nm | ≤ 0.22 dB/km |
| Chromatic Dispersion @ 1550 nm | ≤ 18 ps/nm.km |
| Zero Dispersion Wavelength | 1300 - 1324 nm |
| Outer Diameter | 2.0 x 5.0 mm ± 0.2 mm |
| Net Weight | 20 kg/km ± 2 kg/km |
| Max. Tensile Loading (Short Term) | 600 N |
| Max. Tensile Loading (Long Term) | 300 N |
| Crush Resistance (Short Term) | 1000 N |
| Crush Resistance (Long Term) | 2200 N |
| Operating Temperature Range | -20°C to +60°C |
Reel Length: 2 km per reel, packaged in a single carton box.
Sheath Marking: Brand, Cable type, Fiber type and counts, Year of manufacture, and Length marking as per requirement, at 1 m intervals.
| Container Type | 1KM/roll | 2KM/roll |
|---|---|---|
| 20'GP container | 812KM | 1000KM |
| 40'HQ container | 1900KM | 2000KM |
| Fiber count | 1/2/4 |
| Tight buffer | LSZH, White |
| Tight buffer diameter | 0.90±0.05mm |
| Fiber Type | G657A1/A2 |
| Strength member | Glass yarn/aramid yarn |
| Outer sheath | LSZH Lower smoke zero halogen frame retardant & UV Anti |
| Cable Diameter dimensions | 3.0±0.2mm |
| No. | Items | Unit | Specification |
|---|---|---|---|
| 1 | Mode Field Diameter (1310nm) | μm | 9.2±0.4 |
| 2 | Cladding Diameter | μm | 125.0±1.0 |
| 3 | Cladding Non-Circularity | % | ≤1.0 |
| 4 | Core-Cladding Concentricity Error | μm | ≤0.5 |
| 5 | Coating Diameter | μm | 245±5 |
